Technical specications : I/F w/built-in radio receiver
Fig. 2
RXU4GO128
123
81,5
41,5
Operating frequency ................................... 433,92 MHz
Demodulation .............................................GFSK
Sensitivity ( for good signal ) .....................-115 dBm
Power supply: ............................................. 12/24 Vac/dc
Current consumption ( @12 Vdc ) .............. from 25 to 50 mA (max)
Encryption...................................................AES128 bit
Input ...........................................................RS-485
Outputs ....................................................... Relay, Wiegand
Wiegand protocols supported .....................26 - 30 - 44 bit
Memory capacity ........................................7560 tags
....................................................................100 remote controls
Relays.........................................................2 x 24 VA - max 48Vdc
Relay operating mode ................................pulse , step, delayed
Delay ..........................................................from 1 sec. to 23 h : 59 min
Retransmission period over wiegand bus...from 100 mS to 2 Sec.
Relay pulse ................................................300 mS
Operating temperature: ..............................-10 ÷ +60°C
Enclosure IP protection: .............................IP55
Dimensions: ................................................120 x 80 x 40 mm
Weight ........................................................65 gr.
5
Transmitters Erone 128
Part-name Part-Number Description
S3TR128E2 F1002000089 TRANSMITTER ERONE 128 2 CH
S3TR128E4 F1002000090 TRANSMITTER ERONE 128 4 CH
5
Mounting of the reader
RF Reader
Mounting pole
L-shaped bracket
U-shaped bracket
Fixing screws & nuts
Counter-plate
bracket
