COFFEE GRINDER E5P - E6P - E7P
Main parts (Fig. 1, Fig. 2, Fig. 3, Fig. 4, Fig. 5)
Fig. 1
4
Fig. 2
1
Motor housing
Bean hopper
Support fork
Filter-holder support
Discharge opening
Grinding adjustment disc
Bean hopper shutter
ON-OFF (I-O) switch (E6P - E7P)
Dispensing button (start) (E5P)
Control panel (E6P - E7P)
Hopper lid
6
5
4
3
2
1
11
10
9
8
7
Tray
Single shot selection (start)
Double shot selection (start)
Left multifunction button
Right multifunction button
Container (only in filter models)
