Cecilware FE-100G - Parts List; FE-100 G Gas System Parts

FE-100G
AUTOMATIC GAS
COFFE URN
PARTS LIST FOR FE-100G GAS SYSTEM
NO DESCRIPTION
1 SIDE BOX DOOR RZ46A
2 SIDE BOX RZ45A
3 WASHER 2" P528A
4 HEX BUSHING 3/4 X 3/8 NPT K636A
5 SPACER 1/4" K641A
6 GAS VALVE R/S 7000MVRLC L621A
7 3/8 NPT 4" NIPPLE, BLACK J015A
8 1/4 COMP FITTING K039A
9 1/4 ALUM PILOT TUBE H350A
10 3/8 X 3/8 NPT L COMP FITTING K635A
11 3/8 ALUM GAS VALVE TUBE H349A
12 THERMOSTAT RX-2051-12 L622A
13 WIRING HARNESS CH32A
14 8-32 HEX NUT P010A
15 #10 STAR WASHER P072A
16 8-32 X 3/4" WELD STUD P125A
17 THERMOPILE F178A
18 PILOT ASSEMBLY F144A
19 ORIFICE,NAT F098A
ORIFICE, LP F126A
20 BURNER G090Q
21 MANIFOLD F044A
22 8-32 X 5/8 SCREW P526A
LP CONVERSION KIT L347P
5
