Cecilware ME10E-N - Specifications; Dimensions

WATER INLET
OVERFLOW
POWER
SUPPLY BOX
TEMPERATURE
CONTROL
VENT OPENING
THERMOMETER
NOTE:
1. FIELD WIRING MUST BE SUITABLE FOR 75 DEGREES CELSIUS.
2. USE COPPER WIRE ONLY FOR POWER SUPPLY CONNECTION.
3. 120 VOLT UNITS SUPPLIED WITH A GROUNDED 120V-15A LINE CORD AND PLUG.
4.0
"A"
14.0 4.0
16.03.4
POWER
SWITCH
POWER ON
LIGHT
HEATER ON
LIGHT
SIDE ACCESS DOOR
(SLIDES UP)
TEMPERATURE CONTROL
CAUTION
HOT SURFACES
ME10E-N
