cecotec bongo A+ Series - Troubleshooting; Troubleshooting Common Issues

6362
BONGO SERIE A+ MAX 45 CONNECTED
ENGLISH ENGLISH
ORIGINAL MANUAL TRANSLATION
Battery Type Lithium-Ion - 10INR19/66-
4
Model 60088
Charge time 5-6 hrs
Capacity 12800 mAh
Nominal voltage 36 V
Max. charge voltage 42 V
Max. charging current 3A
Rated capacity 460,8 Wh
Tyres Wheel 10”
Charger Model XHK-985-42020 9
Input 100-240 V 50/60 Hz 2.5 A
Outlet 42V DC, 2A, 84W
Protection IP 20; Ta= 40ºC; Class II
Riding modes and
autonomy (4)
CONFORT 45 km
SPORT 25 km
- (1) Height from the oor to the upper part of the handlebar.
- (2) Check the current local regulations.
- (3) The range measured with a weight of 80 kg, fully charged battery, in Comfort mode on
a at surface, without wind, and with an ambient temperature of approx. 25ºC.
- (4) Measured with a weight of 80 kg, fully charged battery, at surface, no inclination, no
wind, and an ambient temperature of approx. 25°C.
- The total value of the exposed vibration in the hand-arm system does not exceed 2,5 m/s2.
- The weighted acceleration to which the whole body is subjected does not exceed 0.5 m/s2.
- The A-weighted emission sound pressure level at workstations is less than or equal to 70
dB.
8. TECHNICAL SPECIFICATIONS
Product reference: 07303
Model: Bongo Serie A+ Max 45 Connected electric scooter
Features Measuring units Specications
Dimensions Folded 105 x 42 x 45 cm
Unfolded 105 x 42 x 116 cm (1)
Weight Electric scooter weight 14,40 kg
Use requirements Min-max weight 25-100 kg
Min-max height 100-200 cm
Age bracket 16-60 year (2)
Technical
specications
Battery life Up to 45 km (3)
Max. speed 25 km/h
Max. inclination 10º
Operating temperature -10º/40ºC
Storage temperature -15º/45ºC
IP protection rating IPX4
Motor Max. Power 700 W
Rated power 350 W
