BONGO SERIE S+ MAX INFINITY / UNLIMITED
ENGLISH ENGLISH
ORIGINAL MANUAL TRANSLATION
- Check that all parts of the electric scooter are in position and securely fastened.
- Check tyre wear and pressure.
- Check the brakes and throttle cables for wear.
7. TROUBLESHOOTING
Error Possible causes Possible solutions
The motor does not
operate
The battery is not connected. Check the connectors.
Low battery. Charge the battery
Electrical problem. Check all connectors.
The motor turns o
during operation.
Overheating Release the throttle
and wait until the motor
cools down.
After charging it, the
electric scooter switches
o.
The battery is not fully charged. Charge the battery
The battery is frozen. Heat up the battery.
The battery is old or not working
properly.
Replace the battery.
Battery does not charge The charger is broken. Replace the charger.
The connector does not make good
contact.
Replace the charger.
Error codes: If any of the following error codes appear on the display, stop using the electric
scooter immediately and contact Cecotec’s ocial Technical Support Service.
- E1: Motor fault
- E2: Controller-indicator fault
- E3: Throttle fault
- E4: MOS-controller fault
- E5: Phase-current fault
- E6: Average-current fault
- E7: Battery-voltage fault
- E8: Handlebar-brake fault
8. TECHNICAL SPECIFICATIONS
Model Bongo Cecotec Serie S+ Max Innity/Unlimited
Reference 07304/07305
Features Measuring units Specications
Dimensions Folded 110x50x50
Unfolded 110 x 50 x 117 cm (1)
Innity’s weight Electric scooter weight 15,5 kg
Unlimited weight Electric scooter weight 16 kg
Use requirements Min-max weight 20-100 kg
Min-max height 190-130 cm
Age bracket 16-80 years (2)
Technical
specications
Innity’s autonomy Up to 30 km (3)
Unlimited’s autonomy Up to 40 km (3)
Max. speed 25 km/h
Max. inclination 15º
Operating temperature 0º/45ºC
Storage temperature -15º/45ºC
IP protection rating IPX4
Motor Max. power 0,750 KW
Rated power 0,350 KW
