1. PARTS AND COMPONENTS
Fig. 1
1. Top cover
2. Control panel
3. Air outlet/louvers
4. Wheels
5. Front housing
Fig. 2
1. Back housing
2. Filter
3. Continuous-drainage hole
4. Cable holder
5. Air outlet
6. Drainage hole
Fig. 3
1. Air outlet pipe
2. Window sealing plate
Control panel and remote control Fig. 4-5
1. Time/temperature increase
2. On/O
3. Time/temperature decrease
4. Sleep mode
5. Fan-speed decrease
6. Fan-speed increase
7. Heating mode
8. Fan mode
9. Dehumidication mode
10. Cooling mode
11. Oscillation
12. Full-tank indicator
13. Timer
NOTE:
The graphics in this manual are schematic representations and may not exactly match the
product.
2. BEFORE USE
- This appliance is packaged in a way as to protect it during transport. Take the appliance
out of its box and remove all packaging materials. You can keep the original box and other
packaging elements in a safe place. This will help you prevent product damage when
transporting it in the future. In case the original packaging is disposed of, make sure all
packaging materials are recycled accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or in bad conditions, contact the ocial Cecotec Technical Support Service
immediately.
Box contents
- ForceClima 9500 Soundless Heating Connected portable air conditioner
- Window kit
- Remote control
- Instruction manual
3. PRODUCT INSTALLATION
NOTE:
- Leave a minimum of 50 cm distance to walls and other objects. Fig. 6
- Do not install and use the air conditioning in the bathroom or other humid environments.
- Before using the portable air conditioner, keep it upright for at least two hours. When
moving the appliance from one place to another, always do it with the device in an upright
position and leaving it in a at surface.
- The air outlet pipe should be 28-150 cm long, this length is based on the specications of
the air conditioner. Do not use extendible pipes or replace the pipe with a dierent one, as
this may cause the product to malfunction. The exhaust pipe must be clear of obstructions;
otherwise, it may cause overheating.
Installing of the air outlet pipe. Fig. 7
1. Stretch the air outlet pipe.
2. Insert the pipe into the air outlet.
3. Turn the end counterclockwise to x it to the air conditioner body.
NOTE:
The at end of the exhaust pipe joints must be snapped into place.
The air outlet pipe must not be twisted or bent more than 45°. Keep the air outlet pipe free of
obstructions.
