Cedar Summit F25630 - Page 51

Hardware
Wood Parts
4 x #8 x 1-3/8” Wood Screw
S20
Fig. 8.2
2 x Crowsnest Post FSC 1-1/2 x 3 x 31-7/8”
1 x Slidenest Joist FSC 2 x 4 x 29-3/4”
081
080
Step 8: Slidenest Assembly
Part 1
A:Place(080)SlidenestJoistatonlevelground.Using2(S20)#8x1-3/8”WoodScrewspersideattach1
(081)CrowsnestPosttoeachsideofthejoistsotheanglededgesofthejoistaretighttoeachpost.(g.8.1and
8.2)
Note: Thedistancebetweenpostsshouldbe25-3/4”(g.8.1)
Note: Donoallowmorethana1mmgapbetween(080)SlidenestJoistand(081)CrowsnestPost.(g.8.2)
Fig. 8.1
080
Flush
S15
081 081
081
Inside View
S20
080
Flatonground
MinimumGap1mm
allowed
25-3/4”
