4 x #8 x 1-3/4” Wood Screw
Hardware
1 x Slidenest Top FSC 5/4 x 5 x 31-3/4”
Wood Parts
085
081
Fig. 8.8
Step 8: Slidenest Assembly
Part 4
D:MakesuretheSlidenestAssemblyissquarethenattach(085)SlidenestToptoeach(081)CrowsnestPost
with4(S15)#8x1-3/4”WoodScrews.Maintainthe25-3/4”distancebetweenposts.(g.8.8)
Note: Theanglededgesof(085)SlidenestTopshouldfaceoutandushtotheoutsideedgesofeach(084)
SlidenestL&R.(g.8.9)
Fig. 8.9
085
081
Assemblymustbesquare
priortoattachment.
Outside View
S15
081
085
084
Anglededgefacesout
Inside View
Flush
Flush
084
S15
S15
S15
25-3/4”
