Fig. 8.5
Step 8: Slidenest Assembly
Part 3
C:Flushtothetopofeach(081)CrowsnestPostattach1(084)SlidenestL&Rwith2(S15)#8x1-3/4”Wood
Screwsperside.(g.8.5and8.6)Makesuretomaintaintheproperorientationasshowning.8.7.
Fig. 8.6
Fig. 8.7
084
084
084
081
2 x Slidenest L&R FSC 5/4 x 5 x 7”
Wood Parts
084
4 x #8 x 1-3/4” Wood Screw
S15
S15
S15
081
084
Flush
Flush
Top View
