Step 9: Attach Slidenest Assembly to Fort
Part 1
A:WithahelperplacetheSlidenestAssemblyagainstthefrontofthefortso(086)ShortFloorJoististightto
andushtothetopof(043)JoistSide.Pre-drillwitha1/8”drillbitthenattach(043)JoistSideto(086)Short
FloorJoistwith2(S4)#8x3”WoodScrews.(g.9.1,9.2and9.3)
Hardware
Inside View
080
086
043
Fig. 9.2
S4
Front
Fig. 9.1
086
Fig. 9.3
S4
Flush
Outside View
2 x #8 x 3” Wood Screw
