Cedar Summit F25630 - Page 57

Step 9: Attach Slidenest Assembly to Fort
Part 2
B:Makesure(082)SlidenestAssemblyRightand(083)SlidenestAssemblyLeftaretightandushto(030)
NarrowWindowPanels(g.9.4).
C: Attach(082)SlidenestAssemblyRightand(083)SlidenestAssemblyLeftto(030)NarrowWindowPanels
using2(S15)#8x1-3/4”WoodScrewsperboard.(g.9.5)
D:Attachboth(084)SlidenestL&Rto(030)NarrowWindowPanelsusing1(S15)#8x1-3/4”WoodScrewsper
board.(g.9.5)
Hardware
Top View
084
Fig. 9.4
Fig. 9.5
S15
S15
083
030
030
082
084
086
030
043
030
Tightandush
6 x #8 x 1-3/4” Wood Screw
S15
083
082
