8 x #8 x 1-3/8” Wood Screw
HardwareWood Parts
S20
Step 18: Attach Wall Boards to Slidenest Assembly
A:Tighttoeach(081)CrowsnestPostandtighttotheoorboardsattach2(180)WallBoardsto(082)and(083)
SlidenestAssembliesRightandLeftandboth(084)SlidenestL&Rwith4(S20)#8x1-3/8”WoodScrewsper
wallboard.(g.18.1and18.2)
Fig. 18.2
180
Inside Fort View
081
084
083
Tight-NoGap
2 x Wall Board FSC 1 x 4 x 26-1/2”
180
x4per
board
S20
Fig. 18.1
Tight
Right Side
Left Side
081
084
082
Tight
