Cedar Summit F25630 - Page 83

C:Centre(191)SteeringWheelDashon(104)CrowsnestTopand(190)CentreWallBoardthenattachto(104)
CrowsnestTopwith2(S3)#8x2-1/2”WoodScrewsandto(190)CentreWallBoardwith2(S20)#8x1-3/8”
WoodScrewsasshowning.19.4.
D:Measure3-1/4”fromeach(081)CrowsnestPostandattach2(192)WallBoards,between(081)Crowsnest
Postsand(190)CentreWallBoard,tightto(174)CrowsnestFloor,with4(S20)#8x1-3/8”WoodScrewsper
board.(g.19.4)
Hardware
Fig. 19.4
Step 19: Attach Wall Boards to Crowsnest Assembly
Part 2
104
081
081
190
102
S20
x4
x4
S20
S20
191
S3
192
10x #8 x 1-3/8” Wood Screw
2 x #8 x 2-1/2” Wood Screw
S20
1 x Steering Wheel Dash FSC 5/4 x 5 x 12-1/8”
2 x Wall Board FSC 1 x 5 x 26-1/2”
191
192
Wood Parts
S3
Inside Fort View
3-1/4”
S3
