Step 24: Attach Hand Grip to Fort
A: Measure 6” from the top of the oor boards on the left hand side of each Rock Board, pre-drill with a 1/8”
drill bit then attach 1 Hand Grip per wall with 2 (WL3) 1/4 x 1-3/8” Wafer Lags per Hand Grip. (g. 24.1)
Hand Grip
Other Parts
2 x Hand Grip
6”
Hardware
4 x 1/4 x 1-3/8” Wafer Lag
WL3
Fig. 24.1
WL3
