E: Place 1 (2686) Counter Front against (5736) Counter Joists in each assembly so the ends are ush and the
centre (5736) Counter Joists are centred over the pilot holes. Measure 5/8” down from the top of each (2686)
Counter Front on both ends and attach to the (5736) Counter Joists with 4 (S20) #8 X 1-3/8” Wood Screws per
board. (g. 29.7)
Step 29: Counter Assembly
Part 4
Wood Parts
8 x #8 x 1-3/8” Wood Screw
2 x Counter Front 5/8 x 2-3/4 x 40-5/8”
2686
Fig. 29.7
5736
5736
5/8”
2686
Flush
Hardware
S20
S20
