Step 29: Counter Assembly
Part 7
K: Place 1 Sink and 1 Stove in the openings of the each Counter Assembly then attach 4 Mount Clips per
assembly with included hardware to the bottom of the Sink and Stove to secure in place. (g. 29.11 and 29.12)
Important: Use a hand held screw driver and DO NOT over tighten.
Note: To remove the Sink or Stove loosen screw 1/4 turn then twist Mount Clips.
Other Parts
2 x Stove
16 x Mount Clip
Mount Clip
with hardware
Mount
Clip
Sink
Stove
Mount Clip
with hardware
Included
Screw
Fig. 29.11
Fig. 29.12
