RO manual version 1.0
Sting 11 B
CELITRON MEDICAL TECHNOLOGIES KFT
Copyright (C)
Function of main parts
Transformer
24VAC is transformed into 24VAC.
Supply power to RO pump, solenoid valve, and auto flus-
hing.
Low pressure switch
Auto power cut-off when water supply stops.
ON at over 5psi OFF t below 5psi.
Solenoid valve
After machine stop, water supply is cut off and no waste-
water is drained in order to save water.
RO pump
Push the water to pressure of 70-100psi.
High pressure switch
When the water reservoir is filled with water, it cuts off
power and stops the pump.
Auto flush valve
Automatically control the flushing cycle, when the system
is started it first flushes for 15 seconds ON, and then
begin increasing pressure to make water for 30 minutes
OFF, and flush again for 15 seconds. It is ON and OFF
until power cut off by High-pressure switch.
