CellarPro 3000S - Specifications, Cut Sheets, and Cellar Construction



 6
V8.18
II. Specifications, Cut Sheets and Cellar Construction
Evaporator
Model
Dimensions
W x D x H (inches)
Weight
(lbs.)
Running Amps
(with fan on “high”)
3000S
16.6 x 12.6 x 22.1
(incl. mounting brackets)
40 6.2
3000Sh
30.4 x 14.4 x 13.2
(incl. mounting bracket)
63 6.2
4000S
16.6 x 12.6 x 22.1
(incl. mounting brackets)
42 8.9
4000Sh
30.4 x 14.4 x 13.2
(incl. mounting bracket)
65 8.9
6000S
30.4 x 14.4 x 13.2
(incl. mounting bracket)
68 13.1
8000S
46.4 x 14.4 x 13.2
(incl. mounting bracket)
85 15.4
Condensing unit - Indoor Condensing unit - Outdoor
Model
Dimensions
W x D x H (inches)
Weight
(lbs.)
Dimensions
W x D x H (inches)
Weight
(lbs.)
3000S,
3000Sh
13.5 x 18.9 x 9.1 42
19.4 x 23.3 x 18.8
(with cover)
73
4000S,
4000Sh
13.5 x 18.9 x 10.3 45 76
6000S 13.9 x 18.9 x 11.9 54 85
8000S 16.8 x 20.8 x 14 76 107
