Cellini CMD250 - Parts Name; Component Identification

10
1
3
4
2
1. Operation LED indicators
Blue color indicator means dehumidifying in progress;
Orange color indicator means the water tank is full.
2. Air outlet
3. Back housing of machine
4. Front housing of machine
5. ON/OFF Power switch 6. DC power socket
7. Air inlet 8. Water tank cover lid
9. Removable Water tank 10. AC/DC Adapter
11. Power Jack
PARTS NAME
8
9
6
7
5
10
11
