Wall Mounting
39
This unit is VESA-Compliant and designed to be wall mounted with a VESA-
Compliant 200mm x 100 mm mounting kit. Mount this unit according to the
instructions of the wall bracket (not supplied)
200mm
100mm
4 Mounting holes
Screw size MB5 x 10
1. The stand must first be removed. Place the TV face down.
2. Remove the four screws that secure the stand.
3. Remove and store the stand and screws.
4. Use four machine screws to mount the TV on the bracket.
