COMPONENTS
Convector Heater
2 x feet
4 x screws (taped to the plug)
ASSEMBLY
Each foot supplied with this heater (supplied separately in the carton), only requires 2 screws (taped to the
plug), to attach them securely to the heater. The factory has drilled the holes for these in the base of the
heater.
You need to slightly angle the screws into the holes and when you tighten them up they will straighten up
and secure the feet.
The foot comes with 4 holes as it does not matter which way round you mount them. The pictures below
show where the holes are on each end of the heater base for mounting of the feet.
Screw holes in base of heater
Screws in position once fitted to heater
SAFETY DEVICE
This appliance has two protection devices:
The first device, automatically disconnects & reconnects the appliance at a pre-set temperature.
The second device disconnects the appliance permanently in case of overheating, by means of a thermal
fuse. (It is non resettable)
