Page 6SKU 40926 For technical questions, please call 1-800-444-3353.
PARTS LIST
1
2
3
4
5
6
7
8
9
10
PART # DESCRIPTION
Thumbroll
Outside Diameter Jaws
Dial Adjustment Lock
Dial Adjustment
Dial (Red = SAE / Black = Metric)
Slide Scale Lock
Slide Scale Measurement Point (SAE/Metric)
Inside Diameter Jaws
Step Measuring Surfaces
Depth Measuring Surface
NOTE: Some parts are listed and shown for illustration
purposes only, and are not available individually as replacement parts.
PARTS ASSEMBLY
3
10
7
9
2
8
1
4
6
5
