Page 12SKU 98982 For technical questions, please call 1-800-444-3353.
PARTS LIST & ASSEMBLY DIAGRAM
14
Power Switch (15) not shown.
Battery (16) not shown.
Power Cord/Plug (17) not shown.
Screws (18) not shown.
Part # Description Qty. Part # Description Qty.
1 Display 1 10 Lower Stand 1
2 Nut 1 11 Adjustable Foot 4
3 Bolt 1 12 Bolt 4
4 Steel Tube 1 13 Platform 1
5 Steel Base 1 14 Level Indicator 1
6 Bolt 4 15 Power Switch 1
7 Upper Stand 1 16 Battery 1
8 Sensor 1 17 Power Cord/Plug 1
9 Bolt 8 18 Screw 6
