17
3. Place the microwave oven on a dry corrosion-resistant surface.
4. Install the oven so that there is a gap of at least 10 cm between its
rear surface and the nearest wall and at least 5 cm between sides and
nearest walls. The free space above the oven should be at least 20 cm.
5. Free access of air to the oven should be provided from all sides for
adequate ventilation.
6. The oven should be located at least 5 m away from TV sets, radios
and antennae to avoid interference.
7. Do not install a microwave oven in a cabinet.
8. Install the oven so that its rear side faces the wall.
CONTROL PANEL
POWER SELECTOR
100% of maximum output Fast cooking
88% of maximum output Normal cooking
73% of maximum output Slow cooking
52% of maximum output Beverages, soups
42% of maximum output Defrosting
20% of maximum output Warming-up
TIMER
The maximum cooking time is 30 minutes.
Each increment is equal to 1 minute. After 10 minutes each increment
will be 5 minutes.
A special tone will signal that the set time has elapsed.
OPERATION
1. Connect the power cable to a power socket.
2. Ensure that the timer is set to zero.
3. Do not cover the appliance, provide adequate ventilation.
4. Place the utensil with the food in the oven and close the door.
5. Food should always be in some kind of container or utensil!
6. Select the desired power level.
7. Set the cooking time on the timer.
8. If the desired time is less than 2 minute, set the timer to 2 minutes
first and then to the desired time.
9. To suspend the cooking process just open the door at any time, then
close the door. The cooking process will resume.
10. When the cooking time is over an audio signal will sound and the
internal light will go out.
11. If you have removed the food from the oven before the end of the
cooking time, return the timer to the zero position!
ADVICE ON FOOD DEFROSTING
Microwaves do not penetrate most foods by more than 4 cm. Follow the
guidelines below to improve the defrosting efficiency:
• Stir the food during defrosting to obtain uniform heating.
• If the weight of food exceeds 0.5 kg it should be turned over at least
twice.
• Defrosted foods should be cooked as soon as possible, repeated
freezing should be avoided.
Food Weight Defrosting time
Meat 0.1 ~ 1.0 кг 1:30 ~ 26:00 min
Chicken 0.2 ~ 1.0 кг 2:30 ~ 22:00 min
Sea food 0.1 ~ 0.9 кг 1:30 ~ 14:00 min
COOKING RECOMMENDATIONS
FOOD PLACEMENT IN THE OVEN
Place larger and thicker pieces near the sides of the plate and thinner
pieces in the center. Try to place the pieces uniformly, so that they do
not cover each other.
COOKING TIME
Start cooking by choosing a shorter time period and increase it as
necessary.
UNIFORM COOKING
Turn foods such as chicken, hamburgers or steaks at least once during
the cooking process. Depending on the type of food it is recommended
to stir it several times from the sides to the center.
AFTER COOKING
Upon completion of the cooking leave the food inside the oven for some
time to let the cooking process end and for the food to cool down a little.
CHECKING THE DONENESS OF THE FOOD
Take reference to the color and density/hardness of the food. Steam
should emerge from the whole surface of the dish, not only on the
sides. Fowl bones should easily separate from the flesh. Meat should
be free from blood. Fish should be non-transparent and easily broken
apart with a fork.
SAFE USE OF PLASTIC PACKAGING
Some types of plastic utensils are not designed for preparing food with
high fat and sugar content in microwave ovens.
5. MAINTENANCE
- Disconnect the power cable from the power socket.
- Wash the microwave oven regularly, remove all food residues, fat
and other contaminants.
- Use only mild non-abrasive detergents, sponges or soft cloth to clean
the door, housing, door glass and inner walls of the chamber. Do not use
hard sponges and brushes with metallic particles.
These can scratch the surface of the appliance. Non-observance of this
requirement can cause a reduction of the unit’s service life.
- Do not remove the microwave emitter shield.
6. SPECIFICATIONS
- Capacity: 20 l
- Voltage: 220-240 V ~50 Hz
- Power output: 700 W
- Power consumption: 1100 W
- Microwave frequency: 2450 MHz
- 6 power levels
- 30-minute timer
ATTENTION! Be careful: while operation appliance surface can be high.
7. DISPOSAL
Upon expiry of its service life the appliance can be disposed of
separately from ordinary domestic waste. You can turn it over to a
specialized electric and electronic appliance disposal and recycling
centre.
8. CERTIFICATION DATA, GUARANTEE
The service life of this item is 5 years since the date of sale to the
end user, provided the item will be used in strict accordance with the
present manual and the applicable technical standards. Upon expiry of
the service life please contact the nearest authorized service centre for
suggestions as to further operation of the appliance. The manufacturing
date of the appliance is integrated into the serial number (digits 2
and 3 - year, digits 4 and 5 - month of manufacture). Guarantee and
post-guarantee maintenance is provided by the General Service Center
OOO «Larina-Servis» (Russia, Krasnodar), phone: +7 (861) 991-05-42.
The address of the facility authorized with receiving buyer claims,
maintenance and repairs is shown on the website https://centek.ru/
servis, otherwise refer to the store or other legal entity, where you
have purchased this appliances.
The product is provided with the
Certificate of Conformity:
№ ЕАЭС RU С
-
CN.ВЕ02.В.02215/20 of 28.04.2020 y.
