PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and as-
sembly diagram. Keep your invoice with this manual. Write the invoice number
on the inside of the front cover. Keep this manual and invoice in a safe and dry
place for future reference.
GENERAL SAFETY WARNINGS AND PRECAUTIONS
1. KEEP WORK AREA CLEAN AND DRY. Cluttered, damp, or wet work areas
invite injuries.
2. KEEP CHILDREN AWAY FROM WORK AREA. Do not allow children to handle
this product.
3. STORE IDLE EQUIPMENT. When not in use, tools and equipment should be
stored in a dry location to inhibit rust. Always lock up tools and equipment, and
keep out of reach of children.
4. DO NOT USE THIS PRODUCT IF UNDER THE INFLUENCE OF ALCOHOL OR
DRUGS. Read warning labels on prescriptions to determine if your judgement or
reflexes are impaired while taking drugs. If there is any doubt, do not attempt to
use this product.
5. USE EYE AND BREATHING PROTECTION. Wear ANSI approved safety impact
eye goggles and an ANSI approved dust mask or respirator when using this
product. ANSI approved safety impact eye goggles, dust masks, and respirators
are available from Harbor Freight Tools.
SKU 34102 PAGE 2 REV 02/05
Item Description
Dovetail Jig Style
For Cutting
“Half-Blind”
Jigs
Only. Includes ½” Template
Maximum Stock Thickness Capacity 1-1/4” Thick
Top Width Range 5-1/2” To 12”
Front Width Range 5-13/16” To 10-7/8”
Comb Size 1/2”
Eccentric Fixing Allowance 5/16”
Stop Pin Allowance 1”
Dimensions 10-1/4” H x 17” W x 15-3/4” L
Weight 20.90 Pounds
This Dovetail Joint Fixture is designed to be used with 1/4” shank, 1/2”, 14 degree dovetail
bits only. Note: The bit should protrude approximately 1/2” below the Router base plate,
but may need minor adjustment.
