ASSEMBLY and OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
®
Copyright
©
2006 by Harbor Freight Tools
®
. All rights reserved. No portion of this manual or any
artwork contained herein may be reproduced in any shape or form without the express written
consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
Due to continuing improvements, actual product may differ slightly from the product described herein.
2 PC. HVLP SPRAY GUN KIT
94572

Questions and Answers

  • Z
    zruizJul 29, 2025
    What to do if Central Pneumatic Professional Paint Sprayer will not spray?
    • J
      John GrantJul 30, 2025
      If your Central Pneumatic Professional Paint Sprayer isn't spraying, there could be a few reasons: 1. First, ensure there is pressure reaching the gun by checking the air hoses. 2. Next, make sure the fluid control is sufficiently open; adjust it if necessary. 3. Lastly, the fluid might be too thick. If so, thin the fluid or increase the air pressure, but stay within the maximum range.
  • E
    erinrandolphAug 3, 2025
    How to fix sputtering spray from Central Pneumatic Professional 94572 Paint Sprayer?
    • N
      Nicole VaughanAug 3, 2025
      Sputtering spray from your Central Pneumatic Professional Paint Sprayer can be caused by several factors: * Low material level. Refill the material. * The cup is tipped too far. Hold it upright. * Clogged air vent. Clean the vent hole. * Loose fluid inlet connections. Tighten them. * Dry or loose fluid needle packing nut. Lubricate and/or tighten it. * Loose or damaged fluid tip/seat. Adjust or replace as needed.
  • C
    Catherine CarterAug 8, 2025
    Why Central Pneumatic Professional Paint Sprayer has overspray?
    • S
      Shawna MccannAug 8, 2025
      Overspray from the Central Pneumatic Professional Paint Sprayer can occur due to several reasons. You might be moving the sprayer too fast or not parallel to the surface. Adjust your speed to a moderate pace and ensure you're moving parallel to the workpiece. The distance from the workpiece may also be incorrect, so adjust it as needed. High air pressure can also cause overspray, so try reducing the air pressure.
  • D
    Diane PruittAug 13, 2025
    What to do if Central Pneumatic Professional 94572 Paint Sprayer fluid tip leaking?
    • J
      John BishopAug 13, 2025
      If the fluid tip on your Central Pneumatic Professional Paint Sprayer is leaking, it could be due to: a dirty tip (clean it), a packing nut that is too tight (loosen it), a broken fluid needle spring (replace it), or a worn or damaged tip (replace the tip and/or needle).
  • S
    Shannon HuntAug 18, 2025
    Why is air leaking from air cap of Central Pneumatic Professional Paint Sprayer?
    • A
      Aaron KingAug 18, 2025
      Air leaking from the air cap of your Central Pneumatic Professional Paint Sprayer can be caused by: 1. A dirty air valve or seat (clean it). 2. A sticking air valve (lubricate it). 3. A damaged air valve spring (replace it). 4. A worn or damaged air valve or seat (replace them). 5. A bent valve stem (replace it).
  • V
    vlozanoAug 23, 2025
    How to stop fluid leaking from packing nut on Central Pneumatic Professional 94572 Paint Sprayer?
    • C
      Carrie RhodesAug 25, 2025
      Fluid leaking from the packing nut of your Central Pneumatic Professional Paint Sprayer can happen if the packing nut is loose (tighten it without restricting movement) or if the packing is worn or dry (replace or lubricate it with a non-silicone lubricant).

Summary

Safety Warnings and Precautions

Specifications

Unpacking

Air Connection

Control Layout

Preparation

A Comparison: Conventional versus HVLP Spray Guns

Fan Direction and Pattern Adjustment

Fan Direction

Adjusts spray pattern orientation to horizontal or vertical.

Pattern Adjustment

Controls the size and shape of the spray pattern.

Viscosity

Techniques

Maintenance

Solvent Selection

Guidelines for choosing cleaning solvents based on paint type.

Assembly Diagram and Parts List for 1.4 mm Spray Gun

Assembly Diagram and Parts List for 1.0 mm Spray Gun

Troubleshooting

Spray Pattern Diagnosis

Identifies spray pattern issues and their causes.

90 Day Warranty

Central Pneumatic Professional 94572 Specifications

General IconGeneral
BrandCentral Pneumatic Professional
Model94572
CategoryPaint Sprayer
LanguageEnglish
