Page 13SKU 41209 For technical questions, please call 1-800-444-3353.
PARTS LIST
NOTE:
Some parts are listed and shown for illustration purposes only, and are not available individually
as replacement parts.
Part
Description Part
Description Part
Description
1 Screw (6mmx22mm) 38 Rocker 72 Nose
2 Cap Assembly 39 Roll Pin 73 Trip Foot Assy.
3 Gasket 40 Straight Pin (161) 74 Door Hinge Pin
4 Exhaust Bumper 41 Rocker Pin 75 Holding Pawl
5 Head Valve Spring 42 Trigger 76 Compression Spring
6 O-Ring 43 Roll Pin 77 Kickback Pawl
7 O-Ring 44 Trip Lever Guide 78 Screw (6mmx35mm)
8 Head Valve 45 Nut 79 Pawl Drive Pin
9 Head Valve Seal 46 Washer (Piston, Upper) 80 Door
10 Cylinder Sleeve 47 O-Ring 81 Latch Retainer Pin
11 O-Ring 48 Piston 82 Latch Spring
12 O-Ring 49 Washer (Piston, Lower) 83 Door Latch
13 Bullhead Ring 50 Driver 84 Screw (6mmx12mm)
14 O-Ring 51 Driver Guide (Front) 85 Lock Washer
15 Frame 52 Driver Guide (Back) 86 Piston Washer
16 Filter (Optional) 53 Drive Bumper 87 Gage
17 Air Plug (1/4” NPT) 54 Trip Cover 88 Gage Nut Plate
21 O-Ring 55 Elastic Stop Nut (M6x1) 89 Post Retainer
22 Handle End Cap 56 Screw (6mmx22) 90 Receiver Spring
23 O-Ring 57 Spring (Trip Lever) 91 Spring
24 O-Ring 58 Trip Lever 92 Magazine
25 Trigger Valve Cap Assy. 59 Screw (6mmx10mm) 93 Magazine Wear Clip
26 O-Ring 60 O-Ring 94 Spacer
27 O-Ring 61 Feed Pawl 95 Magazine Post
28 Trigger Valve 62 Roll Pin 96 Magazine Bushing
29 O-Ring 63 Hinge Pin Retainer 97 Washer
30 O-Ring 64 Retaining Ring 98 Platform Assy.
31 Trigger Valve Housing 65 O-Ring Feed Piston Cap 99 Cover Hinge Pin
32 O-Ring 66 Feed Piston Cap 100 Gauge Bracket
33 Poppet Orifice Plate 67 Feed Piston Bumper 101 Magazine Cover
34 Compression Spring
68 Feed Piston 102 Cover Retainer
35 O-Ring 69 O-Ring Piston Stem 103 Hex Wrench
36 Trigger Stem 70 Spring (Feed Pawl) 104 Tool Oil
37 Trigger Valve Cap 71 Feed Pawl Pin
