SKU 66872 For technical questions, please call 1-800-444-3353. Page 14
Part Description Q’ty
1 Exhaust Valve Collar 1
2 O-Ring (33 x 1.75) 2
3 Cover Grip 1
4 Screw (5 x 35) 4
5 Cylinder Cap 1
6 Air Seal 6
7 O-Ring (22 x 1.5) 1
8 Exhaust Valve 1
9 Spring 1
10 O-Ring (9.8 x 2.4) 1
11 O-Ring (32 x 2.5) 1
12 Firing Valve Piston 1
13 O-Ring (13 x 3) 1
14 O-Ring (24.5 x 3) 1
15 O-Ring (22.9 x 2.7) 1
16 Piston Head 1
17 Piston Driver Coupling 1
18 Spring Pin (4 x 10) 1
19 Spring Pin (2.5 x 10) 3
20 Driver Blade 1
21 Collar 1
22 O-Ring (44.8 x 2.6) 1
23 Spacer 1
24 O-Ring (26.6 x 2.6) 1
25 Cylinder 1
26 Bumper 1
27 Gasket 1
28 E-Ring (Ø2.5) 1
29 Body 1
30 Nozzle 1
31 O-Ring (11 x 1.05) 1
32 Upper Housing 1
33 O-Ring (8 x 1) 1
34 Conical Spring 1
35 O-Ring (1.9 x 1.2) 2
36 Remote Core 1
37 Remote Housing 1
38 O-Ring (9.8 x 1.9) 1
39 Spring 1
40 Trigger 1
41 Trigger Frame 1
Part Description Q’ty
42 Guide 1
43 Trigger Release Catch 1
44 Compression Spring 1
45 Catch Guide Plate 1
46 Screw (5 x 22) 3
47 Washer (5 x 1.1) 2
48 Spacer 1
49 Spring Pin (3 x 24) 1
50 Trigger Pin 1
51 O-Ring (37.5 x 3.5) 1
52 Tail Cover 1
53 Male Air Coupler 1
54 Screw (4 x 8) 3
55 Driver Guide Cover 1
56 Nozzle Cover 1
57 Safety 1
58 Screw (4 x 18) 2
59 Nozzle 1
60 Nylon Nut (M5) 1
61 Magazine Support 1
62 Belt Hook 1
63 Pusher 1
64 Compression Spring 1
65 Tail Cover 1
66 Step Pin 2
67 Spacer 2
68 Screw (4 x 25) 2
69 Scaleboard 1
70 Screw (3 x 12) 1
71 Pusher 1
72 Spring Holder 1
73 Feeder Spring 1
74 Steel Bar 1
75 Handle Grip 1
76 Exhaust Valve Assembly 1
77 Head Valve Piston 1
78 Piston Set 1
79 Cylinder 1
80 Trigger Valve 1
81 Rack 1
82 Magazine 1
PARTS LIST
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
To Next Page
