Central Pneumatic 68247 - Portable Air Supply Setup

Page 6 @+-*)/93='91<*A,/()'+=(B*4</1(/*91<<*CD"""D"!!DE%F%6 Item 68247
GH@;IJ KL;MHINKO PHNOI;OHOQ;NOGIHRRHINKO
@'8,-/*U2**L+-)10</*H'-*G,44<W*G/),4
G
A
E
E
H
F
B
Non-lubricated Tools Lubricated Tools
A
B
C
C
D
A
V/(9-'4)'+= @,=9)'+=
A Air Hose Connects air to tool
B Filter Prevents dirt and condensation from damaging tool or workpiece
C Regulator Adjusts air pressure to tool D Lubricator (optional) For air tool lubrication
E Coupler and Plug Provides quick connection and release
F Leader Hose (optional) Increases coupler life
G Air Cleaner / Dryer (optional) Prevents water vapor from damaging workpiece
H Air Adjusting Valve (optional) For fine tuning airflow at tool
