Figure 3 — Using the Chuck toTighten the Jaws
Step 6: Turn the Chuck Key to tighten the Jaws. Make sure the Jaws are tight.
Step 7: Put the Chuck Key in a safe place. Do not lose the Chuck Key.
Step 4: By hand, turn the DRILL CHUCK to tighten the Jaws as shown in Figure 2.
Motor Housing
(#17)
Drill Chuck
(#2)
Drill Bit
Figure 2 — Tightening the Jaws
Step 5: Insert the Chuck Key into one of the three chuck holes in the DRILL CHUCK as shown
in Figure 3, mating the teeth of the Chuck Key with the teeth of the DRILL CHUCK.
Drill Chuck
(#2)
Drill Bit
Chuck Hole
(#16)
