PRODUCT SPECIFICATIONS
SKU 95014 For technical questions, please call 1-800-444-3353 PAGE 2
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
UNPACKING
When unpacking, check to make sure that all the parts and accessories listed on pages
15 and 16 are included, and the product is intact and undamaged. If any parts are miss-
ing or broken, please call Harbor Freight Tools at the number shown on the cover of this
manual as soon as possible.
SAFETY WARNINGS AND PRECAUTIONS
1. Do not operate the Pressurized Abrasive Blaster if the Air Supply Valve
(18) does not turn the tool on or off. Any tool that cannot be controlled with its
Air Supply Valve is dangerous and must be replaced.
2. Keep work area clean. Cluttered areas invite accidents.
3. WARNING! Do not operate pneumatic equipment in explosive
atmospheres, such as in the presence of ammable liquids, gases, or
dust. Pneumatic equipment can create sparks which may ignite
ammables.
Item Description
Media Tank Capacity 110 Pounds or 20 Gallons
Working PSI 60 to 125 PSI
Air Consumption 6 CFM @ 60 PSI / 25 CFM @ 125 PSI (with 3/8” Hose)
Air Inlet Size 1/4”-18 NPT
Water Trap Type Push Button to Drain
Hose Dimensions 1/2” I.D. x 1” O.D. x 8’ - 6” Long
Pressure Gauge Indicator 0 <-> 150 PSI (White Face / Red Numbers)
Recommended Media
Type
Glass Bead / Silicon Carbide
Alumina / Walnut Shell / Brass Bead
Accessories Safety Hood / Blast Gun / Funnel
Ceramic Nozzles (2.0mm, 2.5mm, 3mm)
Overal Dimensions 35-1/2” High x 15” Diameter
REV 10d
