ASSEMBLY INSTRUCTIONS

Place the  ame tamers (BG) into the burner box.

Model may not be exactly as shown.

a. Place the cooking grates (BH) into the burner

box, as shown in  gure A.

a. Insert the grease tray (CM) into the opening

in the upper back panel (CO), making sure to

engage tracks located under burner box.

b. Place the grease cup (CN) onto the tracks,

located on the underside of the grease tray

(CM).

Unscrew the electronic ignitor button (CF2) and

insert one AA battery into the electronic igniter

battery compartment, with the positive end facing

outward.

* Battery not included.

CF2

b. Insert the three small positioning rods of the

warming rack (BI) into the rear panel of the

burner box.
