Centroid Acorn Plasma Users Manual Beta CNC12 v4.65 rev6
Position after a Estop/Reset/ESC/Cycle Cancel event.
Note: Configured and wire properly most Hybrid Steppers and AC servos will not lose position during any
of these events so it is usually not necessary to re-home the machine.
4.) Operator Procedure for starting in the middle of a job. Load Job and Set zero’s as normal, then:
a. Press Dry Run
b. Press Cycle Start.
c. Press Restart Mode approximately where you want to start the job
d. Press the Forward or Backward buttons to move to the restart position.
e. Use Jog keys to jog off if a lead in is desired.
f. Press Dry Run again to turn it off
g. Press Cycle Start to start the job at the current torch position.
Page 35 D:\Keith Documents\centroid_acorn_plasma_users_manual_draft27.odt rev27 3-15-22
