Centroid Acorn Plasma Users Manual Beta CNC12 v4.65 rev6
Requirements: CNCPC USB port and Plasma Pro License file.
The four User Programmable Macros are preset for common Plasma functions.
Plasma Macro 1 WMPG button = Set XY 0
Plasma Macro 2 WMPG button = Laser Set XY 0
Plasma Macro 3 WMPG button = Restart Mode Forward
Plasma Macro 4 WMPG button = Restart Mode Backward
• Use the MPG Wheel to Jog the machine for any kind of positioning.
• Sensitivity of the wheel detents are adjusted by the x1,x10,x100 selector.
• Use the MPG Wheel to control the cutting Feedrate on the fly.
• Use the MPG Wheel to control the Target Voltage on the fly.
• 4 axis DRO display
• 4 axis MPG and continuous jogging control
• Robust wireless communication
• No software drivers to install
• Hanger bracket mount w/ magnets
• Smooth motion
•
Long range wireless
•
Robust CENTROID developed drivers
•
Takes 2 AA batteries, run time approx. 1 month
•
USB Plug and Play Transmitter / Receiver
•
Rubber case protector
•
Tactile Feedback domed buttons w/ gold contacts
•
High quality 3M Overlay
Page 43 D:\Keith Documents\centroid_acorn_plasma_users_manual_draft27.odt rev27 3-15-22
beta draft
