Plasma CNC12 Parameters
Parameter # Description Notes
511 THC Target Voltage (Counts) Set by Profile Manager
512 THC Maximum Offset Accel (Steps / Interrupt) Set by Profile Manager THC settings
513 THC Maximum Offset Velocity (Steps / Interrupt) Set by Profile Manager THC settings
514 THC Maximum Offset (Steps) Set by Profile Manager THC settings
515 THC Minimum Offset (Steps) Set by Profile Manager THC settings
516 THC Voltage Error Level Set by Profile Manager THC settings
517 THC Voltage Max Consecutive Errors Set by Profile Manager THC settings
518 Plasma Voltage Divider Ratio Set by Profile Manager THC settings
519 THC Active Delay (ms) Set by Profile Manager
520 THC Velocity Anti-Dive Percentage Set by Profile Manager THC settings
521 Feedrate (Steps / Interrupt) Set by Profile Manager
522 ArcOK Voltage Threshold (Counts) Set by Profile Manager THC settings
523 THC Mode Setting Set by Profile Manager
524 Float Switch used with TorchTip Setting Set by Acorn Plasma Wizard
525 THC Voltage Factor Set by Torch Calibration Macro
526 Pierce-Cut Z Feedrate (Units / min) Set by Profile Manager THC settings
527 Kp Value for THC Set by Torch Calibration Macro
528 Ki Value for THC Set by Torch Calibration Macro
529 Kd Value for THC Set by Torch Calibration Macro
530 Integral Limit for THC Set by Torch Calibration Macro
531 Torch ohmic/conductive touch distance offset value Set by Acorn Plasma Wizard
532 Anti Flicker for Target Voltage Display. Takes an average over a
number of samples. Default value is 5. The higher the sample
number the more averaging is applied to the display voltage.
This has nothing to do with the THC target voltage, purpose of
this parameter is to simply display and easy to read value.
Default value is 5. 5 real time samples
are added together and divided by 5 and
that is the Voltage that is displayed. Base
sample rate is 4000 times per second.
