THC_RX Specifications
Characteristic Min. Typ. Max. Unit
24 Volt Supply Current 0.1 - - A
24 Volt Supply Voltage (Vsupply) 22 - 26 VDC
IN1, IN2 Input On Voltage - >3.2 Vsupply VDC
IN1, IN2 Input Off Voltage 0 <1.0 - VDC
IN1, IN2 Input Operating current - 4 5 mA
OUT1, OUT2 Output Voltage* 0 - 26 VDC
OUT1, OUT2 Output Current - 12 50 mA
Size: 4.0 * 2.6 * 0.7 (W*D*H) Inches
.
*OUT1, OUT2 open drain, voltage describes allowable external pull up
THC_TX Specifications
Characteristic Min. Typ. Max. Unit
24 Volt Supply Current 0.1 - - A
24 Volt Supply Voltage (Vsupply) 22 - 26 VDC
Part Touch Input Voltage - Vsupply - VDC
Part Touch Input On Voltage - < 4 - VDC
Part Touch Input Operating current 10 12 17 mA
ANLV Analog Input Voltage -10 - 0 VDC
ANLV Analog Input Current - 5 - nA
Analog Input Resolution - 12 - bits
Size: 4.0 * 2.6 * 0.7 (W*D*H) Inches
svn://173.167.85.217/hardware/THC_RX/200921/docs/THC_RX_TX_MAN.doc MRR Page 5 of 7
