Power Systems, Inc. 39
ITEM PART NO. QTY. DESCRIPTION
1 0D3086 1 BOX GTS LOAD CENTER
2 0D3092 1 COVER, 12 POSITION GTS LOAD CENTER
3 0C2237 1 TRANSFER SWITCH HOME STANDBY 100A 2P 250V
3A 077220 1 COIL UTILITY
3B 077220A 1 COIL STANDBY
3C 082574 1 INSULATOR-SIDEWALL (NOT SHOWN)
3D 084464 1 LIMIT SWITCH OPERATION (NOT SHOWN)
4 074908 6 SCREW HHTT M5-0.8 X 10
5 024912 1 SCREW HHTT 1/4-20 X 5/8
60A1658 1 LOCK WASHER
, SPECIAL-1/4"
7 063617 1 RELAY PANEL 12VDC DPDT 10A@240VAC
8 0E7889 1 12 CIRCUIT LOAD CENTER 125A/240V
90A1495 4 SCREW HHTT M4-0.7 X 10
10 0A1661 2 RIVET POP .156" X .675"
11 022473 1 WASHER FLAT 1/4-M6 ZINC
12 055450 1 PLUG PLASTIC 1.375
13 0D4684 1 HARNESS ADAPTER PLATE
14 0E7900 1 SUBPLATE, LOAD CENTER
15 056326 10.5" TRIM VINYL BLACK 1/8"GP
16 022152 6 WASHER LOCK #10
17 064526 2 SCREW H
WHS #6-25 X 3/8"
18 0E6155 1 ARM EXTENDER PIN
19 063378 4 HOLDER CABLE TIE
20 0D3094 1 HARNESS,GTS TO MAIN PANEL
21 074138 2 LUG QUICK DISCONNECT NI-S 10X45 DEG BRASS / TIN
22 036933 6 SCREW PPHM #10-32 X 3/8"
23 077033 6 LUG SLDLSS 1/0-#14X9/16 AL/CU
24 048850 1 BLOCK TERMINAL 20A 5 X 6 X 1100V
25 028739 4 TIE WRAP 3.9" X .10"
26 0A2110 4 SCREW SWAGE 1/4-20 X 1/2" ZINC
27 0D3191 1 COVER, RELAY & TERMINAL BLOCK
28 0D3088 1 WIRE HARNESS,GT
S LOAD CENTER (NOT SHOWN FOR CLARITY)
29 073591 2 FUSE HOLDER
30 073590A 2FUSE 5A X BUSS
31 040213B 4 PCB SUPPORT SNAP-IN 1-3/8"
32 0E7888C 3 CIRCUIT BREAKER 20A 1P
33 0E7888 1 CIRCUIT BREAKER 20A 2P
34 0E7888B 5 CIRCUIT BREAKER 15A 1P
35 0E7888A 1CIRCUIT BREAKER 30A 2P
36 0D3320 1 COVER - HARNESS ENTRY
37 0D3093 1 HARNESS
, GTS TO EXT CONN BOX
0D8597 1 HARNESS, GTS TO EXT CONN BOX (8.5KW)
38 075475 2 SCREW PPHM M4-0.7 X 10
39 0A7215 4 SCREW SW 1/4"-20 X 5/8" WITH WASHER
40 0E6193 1 BRACKET, ARM EXTENDER
Section 8 — Exploded Views and Parts Lists
Centurion 11, 13 and 15 kW Air-cooled Generators
GTS Load Center – Drawing No. 0E7973-B
