14
OPERATION
Get Started:
1� Unscrew the xing nut from the motor housing by rotating it anticlockwise.
2� Place the rear guard over the motor spindle and replace the xing nut by
screwing it clockwise�
3� Take the fan blade and push it onto the motor spindle.
4� Remove the guard nut and screw from the front guard.
5� Turn the three clips around the outside edge of the front guard outwards�
6� Hang the front guard over the top of the rear guard and push the clips
inwards until the front guard is fastened to the rear guard�
7� Finally t the nut and screw through the hole in the bottom edge of the
front guard arrowed and tighten with a screwdriver�
8� Adjust the speed, pivot and oscillation of the fan by its controls.
SPECIFICATIONS
Product name FMB26
Power supply AC 220-240 V, 50/60 Hz
Eect 30 W
Included in packaging
- Table fan
- User manual
Dimensions 270 x 210 x 400 mm
Weight 1�26 kg
