CEP 8706GU - Parts Breakdown

Parts Breakdown for:
6506G/GU, 8706G/GU,
7506G/GU, 7706G/GU
ID Part Number Description
1
LID6G G BOX LID (Must have SN# for label)
2
LEGG BOX LEG - PAINTED G SERIES
3
FRAME7706G* RUGGED FRAME (for 8706 & 7706 Series)
4
6375H 50A 125/250V TL INLET- HUBBELL
5
6369H 50A 125/250V TL RECEPT- HUBBELL
6
7788 50A TL RECEPTACLE COVER, BLACK
7
GAS7788* 50A TL RECEPTACLE GASKET
8
520R1 20A 125V UG RECEPT-BLACK
9
205R 20A 125V TL RECEPTACLE-MARINCO
10
306R 30A 250V TL RECEPT
11
7420 20A/30A TL RECEPTACLE COVER, BLACK
12
GAS7420* 20A/30A TL RECEPTACLE GASKET
13
7421 20A UG RECEPTACLE COVER, BLACK
14
GAS7421* 20A UG RECEPTACLE GASKET
15
INT INTERIOR CIRCUIT BREAKER PANEL
16
CB120NS SNAP 20A NGFCI BREAKER
17
CB230NS CB 30A NGFCI SNAP IN BREAKER
18
GF6095 GFCI MODULE FOR G SERIES BOXES
19
GBAR* GROUND BAR WITH SCREWS
20
NB* NEUTRAL BAR 6646601S
21
ENDCAP* END CAP FOR NEUTRAL BAR (2 per 1 NB)
* = Not Shown on drawing
