©2016 Cequent™ Performance Products, Inc. - Printed in Mexico Sheet 6 of 18 76112NP 11-10-16 Rev. B
9. Tighten all M812 CL10.9 fasteners with torque wrench to 75 Lb.-Ft.
(102 N*M)
10. Reattach exhaust: Raise exhaust back into position and reattach to the rubber
isolator.
11. Reinstall fascia: Reinstall fascia: starting from the center of the vehicle lineup and
gently reinstall the rear fascia and all fasteners in reverse order. (Note: reattach any wiring
hardness if removed)
12. Trim appearance panel: Appearance panel will need to be trimmed
or not reinstalled. Obtain owner permission before trimming. Trim
appearance panel as shown. Reinstall if trimmed.
Proper torque is needed to keep the hitch secure to the vehicle when towing.
