PL035/PL037/PL057 Specifications
Items
PL035-TST
PL037-LST
PL057-LST
PL057-TST
Display Type
Color mode TFT
LCD, 256 colors
Monochrome blue mode STN LCD,
16 gray levels
Color mode TFT
LCD, 256 colors
Display Size 3.5" (diagonal) 3.7" (diagonal) 5.7" (diagonal)
Number of Pixels 320x240 160x80 320x240
Display Adjustment X Contrast adjustable with rear VR
Brightness
adjustable with
rear VR
Back Light LED; Life time is 50,000 hours
Touch Screen Yes Yes Yes
3.5" Touch Panel
3.7" Touch Panel
5.7" Touch Panel
Input Power
24VDC±10%; Isolation; Under 5W
CPU RISC ARM 32Bit CPU
Flash Memory 2M Bytes 1M Bytes 2M Bytes
System working Memory 512K Bytes 256K Bytes 512K Bytes
Battery Backed Memory x x
Communication Ports
COM1/9pin Female : RS232;
COM2; 4pin Terminal : RS422/RS485
Real Time Clock X(Optional) X(Optional) X(Optional) X(Optional)
Extension Bus Port X X X
Front Panel Seal IP65 / NEMA 4
Operating Temperature
0~50°C
Storage Temperature
-20~60°C
Ambient Humidity 20-90% RH (non-condensing)
Vibration Endurance 0.5mm displacement, 10-55Hz, 30Min. per X, Y, and Z-axis directions
Shock Endurance 10G, 11ms three times in each direction of X, Y, and Z axes
RFI testing FCC Part15 Class A
Radiated Disturbance Test EN 55022/1998+A1:2000
Electrostatic Discharge Test EN61000-4-2/1995+A1:1998
RF Electromagnetic Field Test
EN61000-4-3/1996+A1:1998
Surge Immunity Test EN61000-4-5/1995
EMC Test Report EN55022/EN55024/EN61000-3-2,3/EN61000-4-2,3,4,5,6,8,115
Net Weight 0.30 Kg 0.32 0.55
Cooling Natural cooling
