Technical information
Product guide – CESAB S200
70
l measurement
The l measurement is the Total fork length.
l
2
measurement
The l
2
measurement is the Truck length including back of fork.
W
a
, turning radius
The turning radius is the necessary Distance to rotate the truck around a virtual
point called the turning centre. The Product Information gives the turning radius
for forks with length = 1150 mm and raised support arms.
W
a
