Technical information
Product guide – CESAB S200
77
Model S214L S214L
Mast Dx Tele Openview Triplex
Lh (mm) 4150 4500
Battery compartment M L
1)
M L
1)
Drive wheel load, kg 450 450 450 450
Support arm load, kg 1687 1720 1726 1760
Castor wheel load, kg 436 465 442 470
Machine weight without battery and load 754 765 799 810
Drive wheel pressure, kg/mm
2
0,24 0,24 0,24 0,24
Castor wheel pressure, kg/mm
2
0,35 0,36 0,35 0,36
Support arm wheel pressure, boggie (4), kg/mm
2
0,44 0,44 0,44 0,45
Support arm wheel, single (2), kg/mm
2
0,65 0,66 0,66 0,67
1) Sideways battery change
Model S220D S220D
Mast Duplex Tele Dx Tele Openview
Lh (mm) 2100 2100
Battery compartment M L
1)
M L
1)
Drive wheel load, kg 570 570 570 570
Support arm load, kg 1729 1766 1743 1780
Castor wheel load, kg 570 595 571 595
Machine weight without battery and load 649 660 664 675
Drive wheel pressure, kg/mm
2
0,27 0,27 0,27 0,27
Castor wheel pressure, kg/mm
2
0,41 0,42 0,41 0,42
Support arm wheel pressure, boggie (4), kg/mm
2
0,44 0,45 0,44 0,45
Support arm wheel, single (2), kg/mm
2
0,66 0,67 0,66 0,67
1) Sideways battery change
Model S212S S212S S212S
Mast Simplex Duplex Tele Dx Tele Openv.
Lh (mm) 1655 4105 4105
Battery compartment M L M L M L
Drive wheel load, kg 671 705 734 763 736 766
Support arm load, kg 1479 1511 1563 1594 1584 1615
Machine weight without battery and load 735 746 876 887 900 911
Drive wheel pressure, kg/mm
2
0,30 0,31 0,32 0,32 0,32 0,33
Support arm wheel, single (2), kg/mm
2
0,61 0,61 0,62 0,63 0,62 0,61
