AFMS, Garmin GTX 33X and 3X5 XPDR with ADS-B 190-00734-15 Rev. 3
FAA APPROVED Page 15 of 17
Section 4. NORMAL PROCEDURES
The procedures described below are specific only to the panel mounted GTX 330 or
GTX 3X5 transponders. Cockpit Reference Guides and Pilot Guides for interfaced
remote control displays will provide additional operating information specific to the
displays or other traffic systems.
ADS-B Out functionality resides within the GTX transponders thereby providing a
single point of entry for Mode 3/A code, Flight ID, IDENT functionality and
activating or deactivating emergency status for both transponder and ADS-B Out
functions. Details on performing these procedures are located in the GTX 330/330D
P G GTX 3X5 S T P G.
4.1 Unit Power On
For GTX 330 installations:
GTX Mode .................................................................................... VERIFY ALT
NO ADSB .................................................................................. CONSIDERED
For GTX 3X5 installations:
GTX Mode .................................................................................... VERIFY ALT
NO 1090ES TX .......................................................................... CONSIDERED
NOTE
The NO ADS-B or NO 1090ES TX Annunciation (or associated display
annunciations) may illuminate as the unit powers on and begins to receive input
from external systems, to include the SBAS position source.
