&RROLQJDQG/XEULFDWLQJ6\VWHP
 
Remove drain bolt
Remove drain bolt, seal gasket from
water pump, and drain coolant.
After drainage, assemble with a new seal
gasket, drain bolt and tighten
Reservoir Tank
Remove two mounting bolts and water pipe
on reservoir tank;
Remove reservoir tank; discharge coolant;
Flush reservoir tank.
Install reservoir tank;
Install water pipe.
