MAINTENANCE
Engine oil maintenance – 500/800 only
Always check and change the engine oil at the intervals outlined
in the Maintenance Schedule. Change oil more frequently under
severe use conditions.
Oil level check (500/800)
1. Place the vehicle on a level surface.
2. Start the engine and let it idle for (20~30) seconds. Stop the
engine and wait a short time for the oil to settle.
3. Remove the passenger seat to gain access to the inspection
cover
1
.
4. Remove the inspection cover by grasping the center hole and
pulling rmly.
5. Unscrew the oil dipstick
2
, remove it, and wipe o with a clean
cloth (500 engine shown).
6. Insert the dipstick back into the dipstick hole, make the dipstick
threads contact the hole surface without screwing it.
7. Remove the dipstick and check the oil level indication. Maintain
the oil level between the upper and lower indicators.
8. Reinstall the dipstick into the oil ller hole, and hand-tighten it.
9. Reinstall the inspection cover and passenger seat.
NOTE:
Cover grommet may come loose. Ensure it is in place before
reinstalling the cover.
MAX
MIN
2
1
1
2
MAX
MIN
800
800
500
500
