CFI EXTEL Hello-v - Gate Automation Installation; Mechanical Installation and Mounting; Electrical Wiring and Power Connection

1
2x0,75mm
2
3x6/10°
2x6/10°
3x1,5mm
2
2x1,5mm
2
RX
TX
230 V~
A
B
30 mA
10 A
TEST
1
2
3
4
6
5
C Numéro
trou
D B A
130 1 65 195 115
120 1 65 185 125
110 1 65 175 135
100 2 95 195 120
90 2 95 185 130
80 2 95 175 140
70 2 95 165 150
60 3 125 185 135
50 3 125 175 145
40 3 125 165 155
30 3 125 155 165
NC
GND
GND
COM
+12V
+12V
+
-
VR6
J4
JP3
VR1 VR2 VR3 VR4 VR5
BAT 12V
ANT PED STP VAPHO PH1 LED MOT2STR TXF
EL.LOCK
LAMP
LD1LD2
P1/SET P2/RADIORESET
MOT1
+
-
JP1
STOP
PHO VA S1 TXF PH1 MOT 2 MOT 1
ANT
*
*
*
*
1°
2°
230V
~
Neutre
Terre
Phase
7
