ON‐COMMAND FOUR‐WHEEL‐DRIVE AND DIFFERENTIAL GEAR LOCK SWITCHES
This UTV is equipped with an on‐command four‐wheel drive switch 2WD/4WD (1) and a front
gear lock switch LOCK/4WD (2)
Select the appropriate drive according to terrain and the conditions.
FEATURES AND CONTROLS
1. 2WD/4WD SWITCH
2. 4WD LOCK
Two‐ wheel drive (2WD): Power is supplied to the rear wheels only.
Four‐ wheel drive (4WD): Power is supplied to the rear and front wheels.
Four‐ wheel drive with the front gear locked (4WD‐ LOCK): Power is supplied to the rear and
front wheels when the front gear is locked ( DIFF.LOCK ). Unlike the 4WD mode, all wheels turn
at the same speed.
-44-
