3-78 FUEL SYSTEM (EFI)
ERROR TYPE ERROR CODE POSSIBLE CAUSES
ERROR_INJECTOR 2_O.C. 16
● INJECTOR 2 NOT CONNECTED
● WIRING FAULTY
● INJECTOR 2 DAMAGED
ERROR_FAN_RELAY_S.C. TO
VBAT
23
● WIRING FAULTY [S.C. between Wire1 that
connecting PIN4 ECU to PIN85 FAN RELAY
and +BATTERY]
● FAN RELAY DAMAGED
ERROR_FAN_RELAY_O.C. 25
● FAN RELAY NOT CONNECTED
● WIRING FAULTY [S.C. between Wire that
connecting PIN4 ECU to PIN85 FAN RELAY and
GND]
● FAN RELAY DAMAGED
ERROR_MAIN_RELAY_S.C. TO
VBAT
26
● WIRING FAULTY [S.C. between Wire1 that
connecting PIN3 ECU to PIN85 MAIN RELAY
and +BATTERY]
● MAIN RELAY DAMAGED
ERROR_MAIN_RELAY_O.C. 28
● MAIN RELAY NOT CONNECTED
● WIRING FAULTY [S.C. between Wire1 that
connecting PIN3 ECU to PIN85 MAIN RELAY
and GND]
● MAIN RELAY DAMAGED
ERROR_ENABLE START
RELAY_S.C. TO VBAT
29
● WIRING FAULTY [S.C. between Wire1 that
connecting PIN5 ECU to PIN85 ENABLE
START RELAY and +BATTERY]
● ENABLE START RELAY DAMAGED
ERROR_DLAMP_S.C. TO VBAT 35
● WIRING FAULTY [S.C. between Wire1 that
connecting PIN6 ECU to DLAMP and
+BATTERY]
● DLAMP DAMAGED
ERROR_DLAMP_O.C. 37
● DLAMP NOT CONNECTED
● WIRING FAULTY [S.C. between Wire1 that
connecting PIN6 ECU to DLAMP and GND]
● DLAMP DAMAGED
ERROR_LAMBDA 1 47
● LAMBDA 1 SENSOR DAMAGED
● LAMBDA 1 SENSOR NOT CONNECTED
● WIRING FAULTY [S.C. between Wire 1 that
connecting PIN22 ECU to PIN1 LAMBDA 1
and Wire 2 that connecting PIN21 ECU to PIN2
LAMBDA 1 or GND]
ERROR_LAMBDA 2 48
● LAMBDA 2 SENSOR DAMAGED
● LAMBDA 2 SENSOR NOT CONNECTED
● WIRING FAULTY [S.C. between Wire 1 that
connecting PIN23 ECU to PIN1 LAMBDA 2
and Wire 2 that connecting PIN21 ECU to PIN2
LAMBDA 2 or GND]
